1000 Hz sampling rate

Measure vibration, evaluate ESC responsiveness, and characterize the dynamic response of motors and propellers

ASTM calibrated load cell

We adhere to ASTM E74/E2428 standards to provide the most precise measurement on the market

I/O API and Python control

I/O API to read and control extra sensors, CAN ESCs, and more.Fully control the software using Python.

Compatible with CAN ESCs

Specifications

Thrust
5000 N
Torque
1500 Nm
Voltage
1000 V
Current
500 A
Angular speed
10,000 RPM
Sampling rate
1,000 Hz

Download the Datasheet

Test very large BLDC motors and propellers

Our frictionless measurement system provides extremely high accuracy measurements.

Flight Stand Software

Dynamic testing with manual or automatic control

Included with your Flight Stand

flight stand thrust stand software

Features
1,000 Hz sampling rate
Real-time testing
Manual and automated control
Python API
Powertrain mapping
Automation wizard
Multi-powertrain testing (DEP)

Acquired Data
Thrust and torque
Voltage and current
RPM
Mechanical and electrical power
Propeller efficiency
Motor efficiency
Overall system efficiency

Automated Tests
Flight replay test
Endurance test
Step test
Ramp test
Constant thrust testing
90% Settling Time Test
+ More

Discover the Software

flight stand 500 kgf

Get a Quote

for the Flight Stand 500
